Perfect multiprobes for a combination of spot checking and unattended deployments. Use with any PC, SVR4A®, NX8X and NX10 Handheld displays.

Compact DS:

Is only 21.5” long and 2.6" in diameter, which makes it very portable.

Supports SDI-12 communication protocol. It will easily connect to a datalogger like Sutron®, Handar®, Waterlog®, or any datalogger that uses SDI-12.

Supports RS232 communication protocol. It will easily connect to a PC or PDA.

Internal Battery Pack. 8 AA batteries for unattended deployments when needed.

Measures up to 10 parameters simultaneously:

• Temperature in °C and °F
• Conductivity in µS/cm and mS/cm
• Salinity in ppt
• TDS
• pH
• Dissolved Oxygen in mg/l and %
• ORP (Redox) in mV
• Depth in meters or feet
• Total dissolved gas “TDG” mmHg
• Self clean Turbidity sensor

Specs Compact DS:

• Size: Outer diameter: 2.6” (6.6 cm)
• Length: 21.5” (54.61 cm)
• Weight: 3.8 lbs/1.7 kg. ( Fully loaded)
• Computer Interface: RS-232, SDI-12 and RS-485
• Memory: 120,000 measurements
• Operating Temperature: -5 to 50 °C
• Maximum Depth: 225 m
• Internal Battery Pack: 8AA
• The Temperature sensor is a 30k ohm variable resistance thermistor. (The temperature sensor is included with every Hydrolab sonde.)
• Range: -5 to 50 °C
• Accuracy: +/- 0.10 °C
• Resolution: 0.01 °C

• Optical Dissolved Oxygen sensor. Hach LDO sensor:
• Range: 0 to 20 mg/L
• Accuracy: +/- 0.1 up to 8 mg/L ; +/- 0.2 above 8 mg/L
• Resolution: 0.01 mg/L

• The Conductivity sensor uses four graphite electrodes in an open cell design.
• Range: 0-100 mS/cm
• Accuracy: ± (0.5% of reading + 0.001 mS/cm)
• Resolution: 0.001

• The pH sensor uses a glass bulb and refillable reference electrode.

• pH:
• Range: 0 to 14 pH units
• Accuracy: +/- 0.2 units
• Resolution: 0.01 units

• ORP:
• Range: -999 to 999 mV
• Accuracy: +/- 20 mV
• Resolution: 1 mV

• Custom-made Pressure sensors with two range options.
• Range: 0 to 25m or 0 to 100m
• Accuracy: +/- 0.05 meters
• Resolution: 0.01 meters

• The Total Dissolved Gas (TDG) sensor uses a pressure transducer mounted behind a rigid gas-permeable silicone membrane to measure the amount of total gaseous compounds dissolved in a liquid. Maximum water depth is 25 m.
• Range: 400 – 1300 mmHg
• Accuracy: +/- 0.1% of span
• Resolution: 1.0 mmHg

• The Self-Cleaning Turbidity sensor measures from 0 to 3000 NTU and includes a user-programmable cleaning system to remove any fouling or debris that could otherwise affect readings.
• Range: 0-3000 NTU
• Accuracy (compared to Stable-Cal): 1% up to 100 NTU, 3% from 100-400 NTU, 5% from 400-3000 NTU
• Resolution: 0.1 NTU from 0-400 NTU; 1 NTU for >400 NTU
• Temperature Coefficient: 0.05%/C

Most common questions and answers:

Q: Does the Compact DS use the same communication protocol as the Datasonde®?

A: Yes. The Compact DS uses the same firmware as the Datasonde® with all its features.

Q: Can I use the Hydras 3 LT to communicate with the Compact DS?

A: Yes.

Q: Can I use the Hydras 3L Pocket software with the Compact DS?

A: Yes.

Q: Can I use my existing Hydrolab® cables to connect to the Compact DS?

A:  Yes. The standard Compact DS comes with the standard Hydrolab® 6 pin cable connector.

Q: I do not like the standard Hydrolab® 6 pin cable connector, can the Compact DS be fitted with a YSI® type connector?

A: Yes. The "Compact DS" can be fitted with an optional YSI® type cable connector with recessed pins for maximum ruggedness and it will work with your existing YSI® cables.

Q: Does the Compact DS have internal memory?

A: Yes, it has enough internal memory for 120,000 measurements.

Q: Which batteries does the Compact DS use ?

A:  The Compact DS is equipped with a 8 AA internal battery pack.  They are designed for short unattended deployments only ( one to four weeks  depending on the setup).

Q: Does the Compact DS require internal batteries when used with the SVR4A®?

A:  No, the Compact DS does not require internal batteries when used with the SVR4® display.

Q: Does the Compact DS require internal batteries when used with the NX8 or the NX10 handheld units?

A: No, the Compact DS does not require internal batteries when used with the NX8 or the the NX10 handheld units.

Q: Does the Compact DS require external power when used with the computer ?

A:  No external power required when internal batteries are installed.

Q: When connected to a Datalogger, can the Compact DS still log data internally ?

A: Yes. The Compact DS can perform all the following tasks simultaneously:

Communicate with a PC or Handheld unit via RS232 or RS422

Communicate to a datalogger via SDI-12 or RS232

Log data to its internal memory up to 4 files at a time, even with overlapping dates
