Ultra rugged design and modular structure.
From field use to desktop operation
Powerful enough to run the most demanding applications.
Field rugged design and modular structure.
Specifications for NX10-R:
Dimensions: 282 x 182 x 26 mm (11.1” x 7.1” x 1”)
Weight: 1250g (2.7 lbs)
Processor: Intel Elkhart lake. Atom® x6413E 1.50 GHz (3.00 GHz boost) 64-bit quad-core
Graphics: Intel® UHD Graphics for 10th Gen Intel® Processors
RAM and Storage: 8 GB / 128 GB
Operating System: Windows® 10 Enterprise LTSC (64bit)
Display:
- 10.1″ capacitive multi-touch (10 points)
- 1920×1200 pixels
- Sunlight readable, 850 Nits
- Glove/rain mode
- Chemically strengthened glass
Buttons Front: Power, touch mode, menu, home, F1, F2
Battery Standard: 11.55V 3520 mAh (40.66 Wh). Hot-swappable
Extended: 10.8V 6700mAh (72.4 Wh). Hot-swappable
Ports:
- 5.5mm DC-in barrel power jack
- 1 x USB C 3.0 Support charging and display port.
- 1 x USB C 3.0 output 5V/3A
- 1 x USB A 3.0
- Docking connector
- 1x micro SDXC
- 1x micro SIM
Communication:
- Cellular (WWAN)
- 5G, 4G/LTE, Verizon 5G
- Sierra Wireless EM9191
- *Data only
- Wireless LAN
- 802.11ac, a/b/g/n
- 2.4GHz/5GHz
- PAN
- BT v5.0
- Audio
- Front-facing stereo speaker
- Microphone
Positioning:
- Dedicated GNSS u-blox NEO-M8U receiver
- GPS/GLONASS/Galileo/BeiDou, SBAS
Cameras:
- Rear 12 megapixels with auto-focus and flash
- Front 5 megapixels
Sensors: 9-axis sensor (Gyro, Accelerometer, magnetometer). Light sensor to automatically adjust backlight
Environment:
- Operating: -20°C to 60°C (-4°F to 140°F). MIL-STD-810G, Method 501.5/502.5 Procedures II, III
- Storage: -40°C to 70°C (-40°F to 158°F). MIL-STD-810G, Method 501.5/502.5 Procedure I
- Drop / Shock: 26 drops from 1.2 m (4 ft) MIL-STD-810G, Method 516.6 Procedure IV
- Vibration: MIL-STD-810G, Method 514.6 Procedure I
- Sand / Dust: IP65, IEC 60529
- Water: IP65, IEC 60529
- Humidity: MIL-STD-810G, Method 507.5 Procedure II
- Altitude: 4572 m (15.000 ft). MIL-STD-810G, Method 500.5 Procedure I
- Additional Security: TPM v2.0
- Optional
- NFC:
- 13.56MHz
- ISO14443A/B, ISO15693
- Scanner
- 2D imager (Honeywell N6703)
